1 Product Overview

The RG-S6220 series switches are the data center-oriented high-density 10G layer 3 IPv6 cassette switches introduced
by Ruijie Networks. They are mainly applicable to the data center to provide the convergence access for the servers.
The RG-S6220 series switches:
Model
RG-S6220-48XS4QXS
V1.XX
RG-S6220-48XS4QXS
V2.XX
RG-S6220-48XT4QXS
RG-S6220-24XS
An SFP+ port supports both 10Gbase-R and 1000base-X.
A QSFP+ port support both 40G mode and 40 x 10G mode.
10Gbase-T is downward compatible with 1000Base-T and 100Base-TX in full-duplex mode.
1.1 RG-S6220-48XS4QXS V1.XX
Specifications
Model RG-S6220-48XS4QXS V1.XX (XX indicates number)
CPU Dual-core CPU, each core with the clock speed of 1.0G
BOOT ROM 8MB
Flash Memory 512MB
SDRAM DDR3 1GB
Extension Module
Unsupported
Slot
Extension Module Unsupported
Fan Slot 4 (support 3+1 redundancy, configure at least three fan modules in one switch)
Fan Module M6220-FAN-F
Power Supply Slot 2 (support1+1 redundancy)
Power Module RG-M6220-AC460E-F
10G
10GBase-T
SFP+
Ethernet
Ethernet
Port
Port
48 N/A
48 N/A
N/A 48
24 N/A
40G 2/4/8G
QSFP+ SFP
Ethernet FC
Port Interface
4 8
4 N/A
4 N/A
N/A N/A
- 1 -
Redundant
Extension
Fan
Module
Slot
N/A 3+1
N/A 2+1
N/A 3+1
2 3+1
Redundant
Power
Supply
1+1
1+1
1+1
1+1
