Ruijie Networks RG-S6220-48XS4QXSV1 Hardware Installation And Reference Manual page 18

Power module 1
indicator
Power module 2
indicator
RCMI port indicator
Fan module indicator
10GBase-Tport
status indicator
QSFP+ port status
indicator
Power Supply
The RG-S6220 series switches support power supply the RG-M6220-AC460E-F. The smart power supply module
supports power management, and the host can read input power, input current, and temperature in real time. The
power supply module supports hot plugging.
The RG-S6220series switches support power supply 1+1 redundancy. To improve the stability and reliability of the
entire system, it is recommended to configure power supply module 1+1 redundancy. When the two power supply
modules work normally, the switch is in the status of current sharing.
Solid yellow
Off
Solid yellow
PWR1
Solid red
Solid green
Off
Solid yellow
PWR2
Solid red
Solid green
Off
Green
Yellow
RCMI
Blinking
Cycling blinking
green, yellow and
red.
Solid green
Fan Solid yellow
Solid red
Off
1—48 Solid green
Blinking green.
Off
49F-64F
Solid green
(4x10G mode)
Blinking green.
Off
65F-68F
Solid green
(1x10G mode)
Blinking green.
The temperature gets to the warning threshold.
The power supply module is not in the position.
The power supply temperature exceeds the normal
working temperature.
The power supply module fails or it is not connected
with the AC power cord.
The power supply module works normally.
The power supply module is not in the position.
The power supply temperature exceeds the normal
working temperature.
The power supply module fails or it is not connected
with the AC power cord.
The power supply module works normally.
The port is not linked up.
The port is linked up in 1000M mode.
The port is linked up in 10M or 1000M mode.
Data are transceiving at the port.
This status helps to locate the device position.
All fan modules are in the position and working
normally.
Only three fan modules are in the position.
1) A fan fails.
2) The number of the fan module is less than three.
The port is not linked up.
Port 10G/1G/100M is linked up.
Port 10G/1G/100M is transceiving data.
The port is not linked up.
Port 10G is linked up.
Port 10G is transceiving data.
The port is not linked up.
Port 40G is linked up.
Port 40G is transceiving data.
