Chapter 1: Product Introduction
– Reverse polarity protection
– Galvanic isolated
*Note: Only one power source (AC or DC) to be connected. No failover
functionality.
Mechanical & Environment
▪ Fanless system design
▪ Color
– Pantone black RAL9005, powder painting for aluminum front bezel
– Pantone black RAL9005 for backlight button membrane
▪ IP protection
– IP65 front bezel
– IP20 back system
▪ Mounting: flush/VESA 100mm x 100mm
▪ Vibration
– Compliance with EN60945 protected
– Sweep 2 Hz – 13.2 Hz at ±1 mm, 13.2 Hz – 100 Hz at 7m/s
2 h on each resonance (Q>5), 2h on one resonance/observed frequency
(Q<5), otherwise (Q=0) 2 h at 30 Hz in all three axes, 12 minutes/axis
▪ Shock
– IEC 68 2-27
– 20G @ wall mount, half sine, 11ms
▪ Operating temperature: -25°C to 70°C
▪ Storage temperature: -25°C to 75°C
▪ Operating humidity: 10%~90% relative humidity, non-condensing
▪ Dimension: 590 x 366.6 x 71.66mm
▪ Weight: 9kg
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Certifications
▪ CE approval
▪ FCC Class A
▪ CCC approval
▪ IEC-60945 maritime standards compliance
2 and for
3
