Chapter 3: System Setup
1. Align the mounting holes on the Mini PCIe module to the mounting
holes on the module bracket.
Mounting
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Module
Holes
Bracket
2. Tighten screws onto the mounting holes to secure the bracket.
41
(M)PPC-240T-HW-01 User Manual
