Chapter 3: System Setup
Installing the Half-Size Mini PCIe Module
1. Install the half-size Mini PCIe module into the Mini PCIe slot.
2. Secure the module with mounting screws.
Mini PCIe
Mini PCIe
Slot
Module
42
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
(M)PPC-240T-HW-01 User Manual
