Chapter 4: BIOS Setup
IT8528 HW Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
Pc Health Status
Smart Fan Mode [Automatic Mode]
FAN Speed 30% under Temp: [35 C/ 95 F]
FAN Speed 100% above Temp: [75 C/167 F]
System temperature : +46 C
CPU Core Temp. (DTS) : +22 C
FAN Speed : N/A
Vcore : +1.773 V
Vcc(+12V) : +11.970 V
: +5.182 V
Vcc(+5V)
Vcc(+3V) : +3.291 V
Version 2.17.1246. Copyright (C) 2015 American Megatrends, Inc.
Smart Fan Mode
Selects the mode of the fan, the options are Full on Mode and Automatic
Mode.
FAN Speed 30% under Temp
Configures the temperature for the fan speed to operate at 30% efficiency.
System Temperature
Detects and displays the current system temperature.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
CPU Core Temp. (DTS)
Detects and displays the current CPU temperature.
FAN Speed
Detects and displays the current fan speed.
Vcore to Vcc(+3V)
Detects and displays the output voltages.
Smart Fan Mode Select
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
