Chapter 2: Jumpers and Connectors

Jumpers

RTC Clear Select

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: JP4
1
3
Pin
Settings
1-2 On
Normal
2-3 On
RTC Clear
1-2 On: default
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.

PWN Mode Power Select

Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP2
3
4
1
2
Pin
Settings
1-2 On
VCC3
3-4 On
VCC5
1-2 On: default
12
(M)PPC-240T-HW-01 User Manual
