www.ti.com
Figure 9. Library Documents and Their Location in controlSUITE
As shown in Figure
inputs/outputs are shown explicitly in the introduction part. In addition, module type, target devices, and
related files are explained in this section.
Figure 10. Snapshot of Typical Target Independent Module
PARK
Description
Availability
Module Properties
SPRUGI6 – September 2010
Submit Documentation Feedback
10, a target independent transformation module is described and the module
This transformation converts vectors in balanced 2-phase orthogonal stationary
system into orthogonal rotating reference frame.
Alpha
Beta
Sine/Cosine
This IQ module is available in one interface format:
1) The C interface version
Type:
Target Independent, Application Independent
Target Devices:
28x Fixed and Floating Point devices
C Version File Names:
IQ math library files for C:
Copyright © 2010, Texas Instruments Incorporated
Park Variable Transformation
Ds
PARK
MACRO
Qs
park.h
IQmathLib.h, IQmath.lib
TMS320C2000 Motor Control Primer
Software Tools
13
