Chapter 3: System Setup

Installing a SO-DIMM Memory Module

1. With the chassis cover removed, insert the module into the SO-DIMM

socket at an approximately 30 degrees angle. Apply firm even pressure

to each end of the module until it slips into the socket. The gold-plated

connector on the edge of the module will almost completely disappear

inside the socket.

2. Push the module down until the clips on both sides of the socket lock

into position. You will hear a distinctive "click" sound, indicating the

module is correctly locked into position.

OPPC 1540HT-J1900/1940HT-J1900 User Manual
