Chapter 3: System Setup
5. Connect one end of the provided cable to the connector on the
module.
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Connect to the
module
6. Install the module to the SATA port via the connector at the solder side
of the module and then secure the module using the mounting screw
you removed in step 2. Connect one end of the provided cable to the
connector on the board.
48
Mounting
screw
OPPC 1540HT-J1900/1940HT-J1900 User Manual
