Chapter 3: System Setup
4. Place the SATA hard drive on the drive bay.
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
SATA drive
Drive bay
5. Align the mounting holes that are on the sides of the SATA drive with
the mounting holes on the drive bay and then use the provided mount-
ing screws to secure the drive in place.
41
Mounting
screw
OPPC 1540HT-J1900/1940HT-J1900 User Manual
