Chapter 3: System Setup
3. Mount the brackets to their corresponding mounting holes located on
the sides of the Panel PC.
Brackets and their corresponding
mounting screws
Bracket
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
4. The photo below shows the 4 brackets mounted in place.
Mounting
holes
55
Bracket
Bracket
Bracket
Bracket
OPPC 1540HT-J1900/1940HT-J1900 User Manual
