Chapter 3: System Setup
Installing the Front Bezel on OPPC 1540HT-J1900 (Optional)
Note: The installation instructions are the same as those for
OPPC 1520T. Images are based on OPPC 1520T.
1. The optional front bezel kit includes a front bezel, brackets, and
mounting screws.
Front view of the bezel
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
2. The photo below shows the rear view of the bezel and the corresponding
brackets and mounting screws needed to mount the bezel.
Brackets
54
Bezel
Mounting
screws
Rear view of the bezel
OPPC 1540HT-J1900/1940HT-J1900 User Manual
