Chapter 3: System Setup
6. Place the SATA drive in the chassis and then use the provided mounting
screws to secure the drive in the chassis.
Connect the SATA data cable and SATA power cable to the connectors
on the SATA drive.
SATA power cable
SATA data
cable
SATA drive
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
42
OPPC 1540HT-J1900/1940HT-J1900 User Manual
