Chapter 1: Product Introduction

Specifications

Panel
▪ LED size: 15", 4:3
▪ Resolution: XGA 1024x768
▪ Luminance: 1000cd/m²
▪ Contrast ratio: 2500
▪ LCD color: 16.2M
▪ Viewing angle: 88(U), 88(D), 88(L), 88(R)
▪ Backlight: LED
Touch Screen
▪ 5-wire resistive (flush panel type)
▪ Touch light transmission: 81%
▪ Touch interface: USB
System
▪ CPU: On-board Intel
Celeron™, Quad core processor J1900, 2.0GHz,
®
2M L2 Cache
▪ BIOS: AMI BIOS
▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L
(Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and
Unbuffered
▪ Storage device:
– 1x external locked CFast socket
– 1x hard drive bay: optional 1x 2.5" SATA HDD or 1x SATA DOM
▪ Watchdog timer: Watchdog timeout can be programmed by software
from 1 second to 255 seconds and from 1 minute to 255 minutes
(Tolerance 15% under room temperature 25°C)
▪ H/W status monitor: monitoring system temperature, and voltage
▪ Expansion: 2x Mini-PCIe sockets (support optional Wi-Fi, 3.5G module)
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Rear I/O
▪ PS2 keyboard/mouse
▪ Audio port: 1x Line-out
▪ Remote power switch
▪ Ethernet: 2x RJ45
▪ USB: 2x USB 2.0; 1x USB 3.0
▪ COM #1: RS232/422/485
▪ COM #2: RS232/422/485
▪ Reset button
▪ 2nd display VGA port: 1x DB15
▪ Power switch
Audio
▪ AC97 codec: Realtek ALC886-GR
▪ Audio interface: Line-out/Line-in (Optional)/MIC-in (Optional) audio Jack
Ethernet
▪ LAN chip: dual Intel
® I210AT Gigabit LAN
▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible
Mechanical & Environment
▪ Mounting: panel/wall/stand/VESA 100mm x 100mm
▪ Power input: 12V~30V DC
▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W)
▪ Vibration:
– IEC 68 2-64 (w/ HDD)
– 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
– 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating)
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
