Chapter 2: Jumpers and Connectors
Dimming Control Input Connector
Connector type: 1x5 5-pin header JST, 2.0mm pitch
Connector location: J5
5
1
Pin
Definition
1
GND
3
Increased input
5
VCC3
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
Decreased input
4
Light sensor input
LVDS MCU FW Debug Connector
Connector type: 1x4 4-pin header, 2.54mm pitch
Connector location: JP5
1
4
Pin
Definition
1
VCC3
2
MCU_TCK
3
MCU_TDIO
4
GND
33
OPPC 1540HT-J1900/1940HT-J1900 User Manual
