- during conversation, LEDs are allways lighting during call
independently on surrounding light conditions
- in the night, LEDs are lighting according surrounding light
conditions independently on call
- during night call, Led svítí pouze při hovoru a podle okolního
osvětlení
Light intensity – here you setup LEDs light intensity
Labels light – name card might be backlighted by 3 ways:
- OFF, name cards will never be back lighted
- in the night , backlighting depends on surrounding light
- name card is permanently back lighted
Light intensity - here you setup backlight intensity
Daylight lower treshold – settings sensitivity ambient light sensor, the lower
limit of the window comparator (range 1-1021)
Daylight upper treshold - setting sensitivity ambient light sensor, the upper limit
of window comparator (range 1-1021)
ATTENTION The lower limit must always be less than the upper limit, as the
difference between the two values is the hysteresis (recommended to
maintain approximately 50)
VARIOBELL - specific configuration assembly (a variant of IPBELLv2)
The number of buttons on basic module - basic module has either one or two
buttons, in this setting ensures that each numbering buttons correspond to reality
Number of extension buttons - here is entered the number of buttons
expansion modules. This number is the sum buttons connected to the basic
module. The basic module is always 1 or 2 buttons. According to the connected
expansion modules are filled with the number keys (one expansion module = 8,
two modules = 16 ...). In the phonebook, is then create the appropriate number
of items (number of buttons = number of phonebook entries = number buttons
on the base module + extension number buttons).
Keyboard connected - yet this model not exist keyboard module
