Alpha Technologies IPBELLv2-01 User Manual page 56

(according SIP device setting). You can record message to SD card
during this time and simultaneously send email.
Maximum call duration – when call is picked up timer for call duration limit is
activated. When you insert empty, then there is no limit. The 10sec
before call end you hear tone after which you can dial character for
call prolongation and by this prolong the call about same time period.
Prolongation key – options are * or # and usage is descriped in „Maximal call
duration"
Ringing cycles count– this option enable repeating of call (or progressive call)
. In phone book is for example filled first and second phone number
and not create group. When come condition for first number: -
ringing time is out
Then second number is dialled. When the same conditions come true
and ringing cycles are setup 2 the whole cycle is repeated one more
time.
Same key pressed again – when you press again the same button then you
setup door entry behaviour. Options are:
Active button by HTTP – if checked, so is possible use http request for remote
activation button (like as press the button. This feature is for easy check
the installation IPBELLv2.
Example:
http:// IPaddress
http:// IPaddress
Dialling timeout – this time concern buttons (keypad) and it is deciding for
correct code inserting. When space between button press is longer
than this time the cod eis not correctly evaluated . Situation:
This time simultaneously prolong dial time at buttons which are initial
numbers of codes.
DTMF dialling timeout – this time concerns incoming calls from telephones and
it is deciding for correct code inserting . The principle is the same as
previous parametr but it concerns codes from telefone.
Keyboard mode – yet for this model doorphone not exist keyboard module.
Camera light – wideangle camera has posibility of extra lighting when light
conditions are not acceptable. The lighting provils by white LEDs
(unfortunately infra LED cant be used but advantage is fully colour
picture). The door entry has dark sensor and you have following
options of lighting:
- OFF, LEDs will never light
56 User manual
IPBELLv2
-
- phone number is busy
- subscriber is not reachable / registrated in network
- call is hang up
- call is repeated
- nothing happen
/button_control?btn=1
/button_control?btn=27
- code keylock provides correct code evaluation
- number dial from keypad –dial end resolution
- remote activate button 1
- remote activate button 27
