Alpha Technologies GDI Bell User And Programming Manual

Gsm door intercom
Hide thumbs

Advertisement

Quick Links

Download this manual
G
S
M
D O O R
I N T E R C O M
GDI Bell
User and programming manual V 2.6

Advertisement

loading
Need help?

Need help?

Do you have a question about the GDI Bell and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpha Technologies GDI Bell

Summary of Contents for Alpha Technologies GDI Bell

  • Page 1 D O O R I N T E R C O M GDI Bell User and programming manual V 2.6...

  • Page 2: Basic Features

    Basic technical parametres: Power supply: 12 (9-24) V AC/DC, 500mA (optionally integrated ACU 1600mAh for cca 30h of operation) GSM : 850/900/1800/1900 MHz dimension: 208 mm x 99 mm x 30 mm buttons: 1 or 2 according to your choice (for every button max.
  • Page 3 Function: Hands free GSM door entry phone with preprogrammed numbers for 1 or 2 buttons with name labels: 1. Outgoing call: After button press is dialled first number from saved list of numbers. The numbers are saved under names ABUTTON1 to ABUTTON7 – it means first number under name ABUTTON1.

  • Page 4: Installation

    Relays might be controlled only from preprogrammed numbers at GDI SIM card. 4. camera mode – selected relay is ON by picking up the call and it is OFF by hanging up the call. 5. lighting mode – selected relay is ON by picking up the call and it stays ON for preprogrammed time after hang 6.
  • Page 5 Assembly of front panel CAUTION! During assembly of the front panel may be needed to connect/disconnect the speaker connector (see schematics)
  • Page 6 GDI Wall mounting Wall mounting assembly you make by attached screws (5mm).
  • Page 7 Cards inserting (name labels) Every button has an individual card holder with a plastic flag. (see the figure below)
  • Page 8 Control emelents and connection Switch SIM reader For operation put For operation to position ON insert the SIM Setting of speaker loudness Loudness is also possible setup by parametr Speaker screw terminal input Relay 2 Relay 1...
  • Page 9 Examples of relay connection Basic connection - 2 electrical locks and possibility control 2 doors ( gates) 2x PSU – possibility to use 2x independent PSU. One for GDI and second for electrical locks. The electrical lock 2 is connected inversaly (fire emergency doors). External camera or lighting activation.
  • Page 10 Start 1. connect antenna and insert the SIM We recommend use SIM without PIN. When you need PIN setup PIN 1234. Release the SIM holder (1). Move it up (2). Insert the SIM in correct position (3) to the holder. Close the SIM holder (4).
  • Page 11 Note: All programmed parametres are saved on the SIM. The SIM you can insert into GDI already preprogrammed or setup GDI after switching ON ( via bellow). When you want use calls rejection ( ringing), ask your GSM provider to switch OFF voice mail at used SIM card! SIM preprogramming 1.
  • Page 12 2. Switch on GDI When all neccessary cables are connected (relay, locks, etc.) CAUTION: antenna must be also connected. Then connect speaker connector and connect PSU. The RED LED lights on and after a while yellow LED start flashing (via table). The GDI signalling by tones or by voice SIM reading, GSM network registration and ready for operation (via table).
  • Page 13 1. During first setting when SIM doesnt contents any ADMINx name is neccessary such number insert to SIM by SMS with command INIT. SMS you can send from various number. When SIM already contents even one number under name ADMINx the command is ignored. 2.
  • Page 14 2. Remove front cover of GDI and insert connector of programing modul into GDI (via picture). On programming modul must light on red LED (It is flashing same way like yellow LED on GDI) 3. Run GDIset programm and setup appropriate port. 4.
  • Page 15 After click to button monitor is shown GDI operation (when operation is not stoped by button STOP) Record savings from monitor to file (for service purposes – record sending) Programming mode After button press STOP programm sends to GDI command for stop and wait for GDI response (via ) Waiting for GDI response...
  • Page 16 Item Buttons It is designed for programming phone numbers under each buttons Item for 1 button Field to programm up to 7 phone numbers Field to programm up to 7 phone numbers for upper button Item for 2 buttons Saving of all programmed parametres including numbers to GDI Reading of all programmed...
  • Page 17 Item Phone Book Phone book of authorised numbers for ringing opening as same as automatic call receiving. Position for name Position for phone number Add line above cursor Delete line with cursor Find inserted name...

  • Page 18: Item Setting

    Item Setting Item Calls Loudness of speaker setting Loudness of microphone setting Way of incoming call receiving: - reject (opening by ringing) - automaticaly picked up calls from numbers at list only - pick up all calls Signalization - Informing GDI tones - Ringing during incoming call - Voice signalling Waiting Call...
  • Page 19 Item relay Parametres setting for relay 1 Parametres setting for relay 2 Relay mode: - camera - light - button - control by SMS Relay control by ringing only from SIM phone numbers Relay control by ringing from all phone numbers DTMF code for relay activation during a call Relay time of activation...
  • Page 20 Item SMS Number where will be sent SMS „ALARM ON” when input is activated Number where will be sent SMS „ALARM OFF” when input is deactivated Input mode: - Input deactivated - Tones when input is activated during a call (open signal) - sending SMS Sending SMS to ADMIN1 with list of numbers which activated...
  • Page 21 Item ADMIN numbers setting Field to save up to 7 ADMIN numbers...
  • Page 22 Item Service It is designed for upgrade of firmware and voice messages in GDI. CAUTION! Unauthorised manipulation can blocked the unit. List of files you want record to GDI ( manually editable) Reading of list from PC List erasing Start of files saving from list to GDI. Indicator shows the process of savings.
  • Page 23 When all neccessary is setup then save it by button Save to GDI. Return from programming mode to monitor mode (restart of GDI) To return to monitor mode (run GDI) click on button „Run“. Programm detects GDI runs the same way like stop: GDI behaviour after restart is the same like during power supply connection (tones,eventually voice messages).
  • Page 24 Table of SMS commands command ( SMS) Functionality READ STAT Reading of GDI status (firmware, time, relays status etc.) READ PAR Reading of all setup parametres READ JMENO Reading of phone number for NAME CLR JMENO Erasing phone number for NAME INIT ADMIN1 +420cc…c Inicialization –...
  • Page 25 WRITE PAR TMGSM:x Time setup up GSM network x: 0 – OFF 1 - ON WRITE PAR TONE:x Setting of acoustic signalization x: 0 – switch OFF 1 – signalling by service tones 2 – ringing of incoming call is ON 4 –...
  • Page 26 WRITE PAR RL1TMON:y Relay1 activation time after ringing in or by code yy seconds y=0-9 WRITE PAR RL1RING:x Relay1 activation by ringing in x=0 – OFF x=1 – ON WRITE PAR RL2COD:yy Code for relay2 activation during call yy= 00-99 WRITE PAR RL2MOD:x Relay 2 modes x=0 –...
  • Page 27 CAL AT+CPBR=x Info about number saved on position x CAL AT+CCLK=”<time>“ Setup time in GDI <time> Format <time>= yy/MM/dd,hh:mm:ss±zz yy – year (00-99) MM – month (01-12) dd – day (01-31) hh – hours (00-23) mm – minutes (00 – 59) ss –...
  • Page 28 Names function saved in phone book NAME function ABUTTON1 - to this number GDI call when button is pressed (upper button) - relay1 or relay2 activated by ringing in - calls are automatically received from this number ABUTTON2 - to this number is called from GDI when number under ABUTTON1 is busy, unreachable, not picked up a call for certain time - relay1 or relay2 activated by ringing in - calls are automatically received from this number...
  • Page 29 BBUTTON1 - to this number GDI call when down button is pressed (version with 2 buttons) - relay1 or relay2 activated by ringing in - calls are automatically received from this number BBUTTON2 - to this number is called from GDI when number under BBUTTON1 is busy, unreachable, not picked up a call for certain time - relay1 or relay2 activated by ringing in...
  • Page 30 ADMIN2 - by ringing in activate relay 1 and relay 2 - Activate relay 1 and relay 2 by SMS - Read GDI status and numbers in phone book by SMS ADMIN7 - Edit name and numbers on SIM card by SMS - Control next features by SMS ( AT commands) - Setup parametres by SMS - calls are automatically received from this number...
  • Page 31 G – input mode: 0 – input deactivated 1 – when input is grounded beeps into call (signalling of opened door) 2 – SMS when input is activated/deactivated H - waiting to dial the next number on the list [1-9] value is in dozens seconds PARRL1 - parametres for relay 1...
  • Page 32 manual). Names ABUTONx, BBUTONx, ADMINx, ALARMON, ALARMOFF, PARGDI, PARRL1, PARRL2 must be written by big letters. Between names and numbers is not a space GDI response for SMS „READ STAT“ READ STATUS: VER: 101 BATTERY:4030mV TIME: "00/01/01,00:01:55" OPER: T-Mobile CZ INP:1 RL1:0 RL1:0...
  • Page 33 GDI tones Except ordinary tones and signalling of GSM communication (ringing tone, busy tone, different provider´s messages) the GDI has own signalling of operation (via setting possibilities). High tone – Alerting      Medium level tone – verify action ...

  • Page 34: Led Signalling

    LED signalling  Permanent light    Red LED Not light  Not light   Flashing space and light same    duration  Yellow LED Short flashing with frequency 2 sec. ▌ ▌ ▌   Permanent light ...
  • Page 35 GDI Bell with backup battery If you have already GDI with a backup battery in the delivery, pull out before operation insulating tape. Do not store the device with a battery pack without insulating tape! Self-discharge can damage the battery, not...
  • Page 36 Inserting the backup battery:  Do not stock the device with installed battery pack! Self-discharge can damage the battery, which are not covered warranty of manufacturer ..  Use only batteries approved by the manufacturer (Li-Ion 14650, 1600 mAh).  Observe the polarity. Never place the inverted battery! It can damage the device.
  • Page 38 Again turn on GDI: moving the switch to the ON position The manufacturer is not liable for defects caused by failure to comply with the prescribed procedure. Technical parametres:...
  • Page 39 Dimension 208 mm x 99 mm x 30 mm Operating position various temperature: -20 to + 50°C Operating condition humidity: 10% ÷ 80% při 30° C Power supply 12 (9-24) V AC/DC, 500mA (optionally integrated ACU 1600mAh for cca 30h of operation) Buttons 1 or 2 up casing (for each button max 7 numbers...
