Summary of Contents for Alpha Technologies IPBELLv2-01
- Page 1 IPBELLv2 - SIP DoorPhone IPBELLv2 – 01 IPBELLv2 – 02 IPBELLv2 – 01C IPBELLv2 – 02C IPBELLv2 – 8 User manual Version 1.0...
- Page 2 Welcome Congratulation to purchase modern VOIP door entry systém „Vo IP D hone BELLv2” IPBELLv2. This door entry widely satisfy your needs for communication to visitors of your company, homes, schools etc… Simply VoIP means “Voice over Internet Protocol” – this door entry is connectable to IP network and allows 2 ways of calling.
-
Page 3: Table Of Contents
Contents BASIC DESCRIPTION ..................5 ...................... 5 EATURES ..................6 SED TERMINOLOGY Modules composition ................8 Pushbutton Modules ................. 9 IPBELL 2 ................10 ONNECTION IPBELLv2 basic module ................ 10 Power supply - terminal (20) ..............12 The exit button, door sensor - terminal (19) ........... 12 Expansion bus for buttons - terminal (13) .......... - Page 4 ..................31 URRENT STATUS Language settings ................... 32 .................. 32 NETWORK SETTING IP Network setting .................. 32 SIP setting ....................35 WEB server ..................... 39 4.10 ..................... 41 ASIC SETTING 4.11 Phone book ..................... 41 4.12 Relays ...................... 44 4.13 Door sensors ...................
-
Page 5: Basic Description
1 Basic description Features audio is full duplex with ECHO cancellation phone book for 999 subscribers with 5 tel. numbers for each (max. 130 physicaly buttons + keyboard) every subscriber has more phone numbers with progressive or simultaneous calling ... -
Page 6: Used Terminology
Used terminology Incoming call - Connection between a Brave and a phone made by selecting an option on the phone. The Brave connects the call after set number of rings. The Brave can be programmed from the phone following a connection by inputting a password. - Page 7 Intranet is PC network similiar to internet but it is „private“. It is designed jsut for small group of subscribers (for example workers in some company) PoE (Power over Ethernet) is powering via data network cable. NTP (Network Time Protocol) is protocol for synchronization of internal PC clocks ...
-
Page 8: Modules Composition
Modules composition Door entry IPBELLV2 includes modern technology, timeless design and user friendly installation and service. Door entry IPBELLV2 is equiped by 2 relays and PoE feeding. Basic models are different by using one or two buttons. Furthermore, different models equipped with a color camera. -
Page 9: Pushbutton Modules
1.4 Pushbutton Modules IPBELLv2-01 IPBELLv2-02 IPBELLv2-01C IPBELLv2-02C Expansiom module IPBELLv2-8 User manual IPBELLv2... -
Page 10: Connection Ipbell V 2
Connection IPBELLv2 IPBELLv2 consists of a base plate and a camera module. On the bottom side, wire terminals for two buttons and lighting cards. The camera module is equipped with signaling status, sensor lighting, white LED for illumination around at night for a color camera. We recommend you purchase a model with a camera, because the audio model is deprived of these functions. - Page 11 11. PoE module (supply doorphone UTP cable from the switch - injector according to IEEE802.3af) User manual IPBELLv2...
-
Page 12: Power Supply - Terminal (20)
12. CPU module 13. Connection of cable FK1 Expansion Module (s) - Flat cable, on both sides of the red connector on the side not matter, and also the order of the expansion modules does not matter 14. Switching contact screw terminal of first relay (NC= closed in stand by, NO=open in stand by and COM= common output) 15. -
Page 13: Expansion Bus For Buttons - Terminal (13)
1.9 Expansion bus for buttons - terminal (13) This bus lets you connect expanding buttons to the number 128 + two buttons on basic module = a total of 130 keys. Inch switch DIP4 on each expansion module determines extent to which the 8 keys on a particular expansion module. -
Page 14: Connecting Expansion Modules Ipbellv2-8
E1 – connectors for cable connection FK1 E2 – DIP switch specifies the numbering of the buttons (see below) E3 – Connection lighting cards (depending on the polarity - plus = A, minus = -) E4 – Connection buttons COM is the common wire Mechanical modifications consist in breaking the plugs on the respective sides of the panel to the right or left. -
Page 15: Button Numbering
1.12 Button numbering Numbering buttons in the door IPBELLv2 system depends on the settings in the Web interface (page "Doorphone") switch settings for each button module Numbering not depends on how the (order) bonding button modules. First, it must be determined how many buttons a base module and how many buttons will be the expansion modules in total. - Page 16 User manual IPBELLv2...
-
Page 17: Assembly Of The Ipbellv2 Doorphone
2 Assembly of the IPBELLv2 doorphone 2.1.1 Dismounting of the front cover 2.1.2 IP Bell mounting on the wall Mounting is done with wall plugs and screws. We suggest wall plugs with 5mm in diameter, the screw with half-round head, diameter 4mm, length 35mm... -
Page 18: Replacement Of Visit Cards
2.1.3 Replacement of visit cards Each pushbutton has got its own label held with the white plastic cup (see the figure above). Demounting and inserting of the cap can be done with two fingers along the longer side of the cap by a soft pull / push. 2.1.4 Demounting and mounting of the pushbutton on the front panel User manual... -
Page 19: Closing The Front Cover Of Ip Bell
2.1.5 Closing the front cover of IP Bell 2.2 Interconnection of two modules (under development) User manual IPBELLv2... -
Page 20: Wiring Of Switch
2.3 Wiring of switch Examples of connection are shown on the following page, it's not all possible connections and connection of switches, but they give instructions on how to wire the individual circuits (red circles with numbers = number of examples). 1. - Page 21 User manual IPBELLv2...
-
Page 22: Poe Power Supply
2.4 PoE power supply The IPBELLV2 is equiped by circuit for powering via UTP cable – PoE. When you have IP switch with PoE, or you have PoE PSU (box of adapter size inserted into UTP cable input – according directive IEEE802.3af) then you dont need extra 12V PSU for door entry powering. -
Page 23: Code Relay (Cosw)
2.5 Code relay (COSW) switch available, code relay (COSW CodeSwitch). It serves mainly to protect transmission information about switching electric lock. When using this function can not be by connecting disconnecting the voltage at the terminals to lock this lock activated. Electrical lock is activated only when is compare serial information transmitted between IPBELLv2 (setting security code at Realy page) and board code switch (DIP switch combination). -
Page 24: Micro Sd Card
Micro SD card Micro SD card is used to save users sound files and in near future also to save pictures, video, as record machine. When you select users tone and microSD will not be inserted then tones of basic signalling will be used. Never take out SD card during door entry operation! User manual IPBELLv2... -
Page 25: Service Of Ipbellv2
3 Service of IPBELLv2 Signalling overview The door entry IPBELLv2 signalling acustically stages which occurs during operation. Further signalling is by 2 colour LED (placed right under black plexi). Acustical signalling for each status mentioned in bellow table might be switched off or might be used default tones “beeping”... -
Page 26: Button Press - Code Lock
1. Phone book position for selected button must be permitted 2. Must be fill min. 1 from 5 phone numbers (or IP adresses in P2P mode) 3. At filled phone number is active time plan in appropriate time or no plan is selected. -
Page 27: Visitor Inside Building
Visitor inside building By person inside building is person who is in communication with door entry IPBELLv2. 3.7 Outgoing call Outgoing call is call from door entry (start by visitor). After door entry dial is ringit phone inside the building. When call is picked up you can talk to visitor at door and by code dialling you can activate relay. -
Page 28: Video
Video At models with camera is possible received video as follow: - IP phone with LCD display - PC – WEB browser - PC with programm UDVguard (www.alphatechtechnologies.cz) - PC with general programm for video watching (for example VLC) - Android device (smart phone, tablet) UDVguard (Google Play) - Apple device (smart phone, tablet) UDVguard (AppleStore) Video formats: JPG, MJPG, H.263, H.264 Video for WEB:... -
Page 29: Parametres Programming
4 Parametres programming Parametres programming is performed by ordinary WEB browser. (Caution! version of IE V7 and lower are not supported). WEB interface access For successful display of WEB interface of IPBELLv2 door entry we go through some details. Field length - names, titles, codes, passwords have fix length 40 characters. - URL and etc. -
Page 30: Login
2. Generally in PC setup you program temporarily own IP address.In PC door entry segment for example 192.168.1.10. After change of door entry IP address you have return setting in PC back. Then you can setup parameters of door entry including IP address and after restart of IPBELLv2 door entry you can login to door entry WEB page on new IP adress. -
Page 31: Current Status
Current status Current status display basic data about IPBELLv2 door entry status. It displays Firmware version,door entry model, options connection (camera), SD card, MAC adresses, current time, network setting, door entry mode (P2P or SIP server), registration status and small calls statistic. User manual IPBELLv2... -
Page 32: Language Settings
4.5 Language settings After language selection please don’t forget click on „Save changes“. On the right top corner is display flag of current used language in whole WEB interface. After click on flag accessible language will be displayed. After language selection please don’t forget click on „Save changes“ otherwise language selection wont be performed. - Page 33 After performing of required changes please don’t forget click on „Save and restart“. Setup via DHCP - ON / OFF using DHCP assignment of IP adresses IP adress, Network mask – IP adress setting, mask. In case of emergency please contact your network administrator Network gateway –...
- Page 34 DHCP configuration: After performing of required changes please don’t forget click on „Save and restart“. DHCP – by mark of this checkbox as same as saving and restart will be assigned to door entry IPBELLv2 - IP adress by DHCP. NAT policy - there is the choice of what kind of translate IP addresses used NAT address - used for network traffic through the router (modifies transcription of the original or destination IP address)
-
Page 35: Sip Setting
4.8 SIP setting The door entry IPBELLv2 might operates in 2 basic SIP modes. It is either SIP server – door entry registration is performed to SIP server and then you call to phone numbers assigned by SIP server or Peer to Peer (P2P) – door entry call exact IP adress and SIP server services can´t be used. - Page 36 Account - unit name in SIP protocol (usually line number or name without diacritics) Auth.ID - name for SIP server registration Password - password for SIP server registration Send register – when registration is necessary (mostly yes) then this parametr must be used Registration server - IP adress or server name of registration server (in most systems and installations is enough to insert IP adress).
- Page 37 Peer to Peer mode (P2P) After performing of changes please don’t forget click on „Save changes“. Display name – name by which is device presented in network (for example will display as door entry name in programms UDV panel, UDVguard) SIP User Agent –...
- Page 38 SIP Transport - TCP or UDP, or automatic selection Provisional code - determine if during ringing will be sends SIP code „180 Ringing“ or „183 Session progress“ Enable symetric RTP - by mark is ON. It means that door entry will not sends by itself audio to RTP called party, but wait for called party to send RTP.
-
Page 39: Web Server
4.9 WEB server After performing of changes please don’t forget click on „Save and restart“. WEB interface TCP port - posibility of chase usuall TCP port 80 to other (security reasons) Service password / Retype password – inserting of new access password (instead default password 1234) –... - Page 40 Video password – inserting of new video access password (instead default password 1234) – length max.40 characters (name for video access is video) Enable telnet – available only for special customization. posibility ON / OFF access from telnet (name: root, pass: 8765). telnet is not recommended, in practice, this possibility has caused a lot of problems.
-
Page 41: Basic Setting
4.10 Basic setting In this part are setup user and most often changed parametres. 4.11 Phone book After performing of changes please don’t forget click on „Save“. The phone book contents 999 subscribers. For first 99 subscribers agree subscriber number with button number. In this version of door entry – IPBELLv2 is max = 87 button. - Page 42 Every position of phone book allows insert up to 5 phone numbers with possibility to join some of them (or all) into group and call group of phone numbers simultaneously. Title – This text has informative character only. In case of display using will be name shown in list selection.
- Page 43 according buttons 1 – 2 in this model). Each subscriber has one cod efor every relay. Calling – description The group means that 2 or more phone numbers creates group and those Numbers are dialled simultaneously (all are ringing together). Who from dialled Subscribers pick up first can talk and ringing to other subscribers in group Will be ended.
-
Page 44: Relays
4.12 Relays After performing of changes please don’t forget click on „Save“. In relays setting are accessible 4 relays. The relays 1 and 2 is output of relays contacts directly in IPBELLv2 door entry. Next 2 relays (3 and 4) is possible use for remote relays (IP relays via follow) or as virtual relay usefull for synchronization to allows creation of more difficult functions of relays. - Page 45 function. When such status repeats regularly (for example school) you can use time plan. Time table – defines time period when relay is working and hen not. For example is shop operation time , school, etc.. Relay mode - monostable – by code is closed and after preprogrammed timeout is open.
- Page 46 Synchronize delay – time between synchronization start and its evaluation. Usage for example in more relays closing combination for one code Active on call – options are none (calling has no influence for relay status) incoming call – relay closed during incoming call. The monostable for preprogrammed time.
- Page 47 control of mechanical bell. During button press is relay activated in monostable mode for closing time. If in the phonebook filled for this button telephone number then be combined with relay closing with calling telephone number. RC command at relay ON – Enable setup command sends to external device (for example WEB relay) during relay closing.
-
Page 48: Door Sensors
4.13 Door sensors Door sensors are special functions of door entry IPBELLv2 which is optional. It is HW option which is different according button number of each model – inputs for door sensors. There is created information in the system about close/open the door. -
Page 49: Setting Snmp
Input door sensor 1 / 2 Exit button – relay 1-4 – because the use of door sensors not found so wide usage, so these can be used as two inputs to the function Exit button. When the input connections (short) so activates the corresponding relay (switch monostabile) . -
Page 50: Time Profiles
Admin adress – setup IP adress or domain name of server where are sent information according defined setting Variables in MIB tree – is designed for identification of none sense numeral chain OID OID is numeral identificator which definitely identify every value in SNMP communication. - Page 51 Timetable name – for easy orientation you can named every profile. Period setting table – profile is active when current time match with setup periods. Every day might have up to 3 active periods. Further is possible deactivate whole day (first item on the row select „Active“ – Yes /No) .
-
Page 52: Date And Time Setting
4.16 Date and time setting After performing of changes please don’t forget click on „Save“. Time zone – selection of installation time zone Network time server – IP adress or domain name of NTP server. When you dont know then by inserted * will IPBELLv2 find NTP server automatically according own selection. -
Page 53: E-Mail
4.17 E-mail When you want inform subscriber about missed calls from door entry you can setup IPBELLv2 to sent out email after every missed call. You can setup own subject and text of email. When you have door entry with camera you can automatically add to email one or more pictures from camera. - Page 54 SMTP port – adjust in case of none standard SMTP server setting only. SMTP port is setup usually on value 25, but better is use port 587. SMTP, there are three systems: Port 25 not allow encrypted - it is marked as obsolete, insufficient safety Port 465, not a domain hosting - is labeled as not recommended at Port 587, has no maladies previous two, is currently the only recommended variant...
-
Page 55: Extended Setting
4.18 Extended setting This part is designed for system setting which are done once during installation or when are problems with device kompatibility. 4.19 DoorPhone After performing of changes please don’t forget click on „Save“. Ringing timeout – time for which is ringing. When is setup more numbers as same as progressive ringing then after this time ringing is ended on first phone number (IP adress in P2P) and starts ringing on second. - Page 56 (according SIP device setting). You can record message to SD card during this time and simultaneously send email. Maximum call duration – when call is picked up timer for call duration limit is activated. When you insert empty, then there is no limit. The 10sec before call end you hear tone after which you can dial character for call prolongation and by this prolong the call about same time period.
- Page 57 - during conversation, LEDs are allways lighting during call independently on surrounding light conditions - in the night, LEDs are lighting according surrounding light conditions independently on call - during night call, Led svítí pouze při hovoru a podle okolního osvětlení...
-
Page 58: Audio Setting
4.20 Audio setting After performing of changes please don’t forget click on „Save“. Speaker volume + Microphone gain – amplification setting ECHO limiter – it is designed for Echo cancellation which is created by distortion of loud signal.During standard door entry call is working automatic adaptive echo canceller which cancel the echo after cca 3 seconds of talk and call is full duplex. -
Page 59: Audio Codecs
- default, simple signalling in default setting - user, this is recorded signalling by user ( SD card) -via. Service Volume – loudness signalling adjustment 4.21 Audio codecs After performing of changes please don’t forget click on „Save“. Priority – setting of codecs priority for usage. Some audio codecs requires payable license (for example G729) –... -
Page 60: Video Setting
4.22 Video setting After performing of changes please don’t forget click on „Save“. Image size– image size selection. Stream H.263 knows just CIF resolution (352x288) so bigger image is cut and smaller image is framed Images per second – this setting concern mainly image transmission to WEB browser. -
Page 61: Video Watching (Popup Programm)
2. Aperture priority mode – automatic exposure is adjusted by the camera module 3. Software mode – exposure calculates and sets the software in IPBELLv2 Before adjusting image parameters, it is recommended to use the first Default values.. 4.23 Video watching (PopUp programm) The door entry video records by USB WEB camera. -
Page 62: Video Codecs
4.24 Video codecs After changes performing please don’t forget click on „Save“. Priority – setting of codecs priority for usage . Compatibility – Due some of VOIP phones producers specialities you have to use in certain cases extra setting: Yealink – phonesYealink SNOM –... -
Page 63: Streaming
4.25 Streaming After changes performing please don’t forget click on „Save“. Enable streaming – permitted / prohibited to provide video (H.263 and H264) by door entry IPBELLv2 (server) protocol RTSP on port 554. To receive such video you need some standard stream video players (IP TV or for example Grandstream, MPlayer, VLC etc…). - Page 64 Multicast adress – by inserting IP adress you permit sending RTP packets to selected multicasting adress. JPEG image quality – you insert percentage of video coding quality User manual IPBELLv2...
-
Page 65: Service
4.26 Service This part contents service functions. 4.27 Restart By click on „Restart“ button you make door entry reset. User manual IPBELLv2... -
Page 66: Configuration
4.28 Configuration The door entry IPBELLv2 allows saving of current setting to PC or other repositury. From this saved file you can later restore this setting in a few levels – for example phone book only. It helps for example during installation of door entry in more entries to the building. -
Page 67: Language And Style
Default network and SIP – make default setting of network (IP adress 192.168.1.250) and erase SIP setting Default Others – all remains parametres put to factory setting By click to „Make” will be done required setting/erasing door entry parametres. 4.29 Language and style Load Style file –... -
Page 68: Style And Language Preparation
Load logo file – by click to empty field select the file and by click to „Make” is logo file. Logo file is standard picture /JPG or GIF or BMP or PNG/ with dimension about 200 x 100 px and name logo.* Clean languages –... - Page 69 To create new language we recommend following steps. Firstly make export of language file (language version of exported file is simultaneously selected language ( flag in right top corner). Rename this file to new language and open in text editor (PSPad is recommended because file has rows ended by LF only and no CR+LF as usual).
-
Page 70: Firmware Upgrade
4.31 Firmware upgrade Firmware version – display present firmware version in door entry IPBELLv2 Choose firmware file – by click to empty field select file with firmware (for example apt.firmware it is not file *.zip, but already unzip file – on website are firmware files packed to archive *.zip) In Windows is display proces so firmware upgrade. -
Page 71: Logfile
After firmware upgrade you must make restart of doorphone IPBELLv2. 4.32 Logfile Start enhanced log – it is OFF in default to save processor efficiency. When you switch it ON then are save into internal memory detail information about door entry operation. It is very helpfull to solve different problems ( compatibility etc..). - Page 72 Show call log - in new WEB interface window are online display information about making calls. Syslog server – IP adress or server name of syslog server where will be sent records about IPBELLv2 door entry operation (do not forget setup NTP server for setting of internal door entry clocks otherwise records will be saved with incorrect date and time) The procedure to download Enhanced LOG file.
-
Page 73: License
4.33 License This page allows extend door entry features about payable functions via licenses.For example audio codec G729. After payment you receive license number by email License validity shows if license is working correctly. The license code is connected to MAC number of door entry. User manual IPBELLv2... -
Page 74: Sound Files
4.34 Sound files This page is designed for recording own (user) sounds signalling. By click on „Play“ will be played currently active sound file (selection is permormed on page „Audio setting“ eventually sound of relay closing on page „Relays“). Attention files are recorded on a microSD card! Audio files: WAV –... -
Page 75: Technical Parametres
Max. switching current by relays when U < 30 V - 20 to + 80°C Temperature range Mechanical dimensions Type of doorphone Size HxWxD [mm] IPBELLv2-01 208 x 99 x 30 IPBELLv2-02 208 x 99 x 30 IPBELLv2-01C 208 x 99 x 30 IPBELLv2-02C... - Page 76 User manual IPBELLv2...
-
Page 77: Video Parametres
Video parametres Video formats: JPG, MJPG, H.263, H.264 Video for WEB: Internet Explorer, Mozilla, Opera, Firefox… - (set of JPG pictures - Port 80) it is used repeated http request „IPaddress/video.jpg“ programm PopUp (UDVguard) - (MJPEG stream - Port 80) is used http request „IPaddress/video.mjpg“... -
Page 78: Requests
5.3 Requests VIDEO: http:// IPaddress /video.jpg MJPG - http:// IPaddress /video.mjpg H.263 - rtsp:// IPaddress /video.263 H.264 - rtsp:// IPaddress /video.264 RELAYs: http:// IPaddress /relay_control?1=on http:// IPaddress /relay_control?1=off http:// IPaddress /relay_control?2=on http:// IPaddress /relay_control?2=off http:// IPaddress /relay_control?3=on http:// IPaddress /relay_control?3=off http:// IPaddress /relay_control?4=on http:// IPaddress /relay_control?4=off BUTTONs:... - Page 80 Guarantee conditions: The product was shop-checked. The producer guarantees that this product will keep the features described in these operating instructions in the course of guarantee provided that the user will be handled with it as described in the operating manual. Particularly the warranty does not cover damage from improper intervention via Telnet.
- Page 81 © Alphatech Technologies s. r.o. 2014-2017...
