5.4 Video Timing Parameters

The SM731 must be programmed to generate the proper video timing for
the hardware configuration and display format. Rastergraf' SDL Graphics
Package accepts display format (e.g., 1600 x 1200, 32 bpp) and refresh
requirements (e.g., 67 Hz vertical refresh) as parameters to a function call.
The software then provides (and loads) a best-fit timing profile for the
SM731 graphics chip.
Does your Display have a Green Cast to it?
By default, the graphics board supplies video in separate (five wire video
RGBHV) video format. If you hook the board up to a multiscan monitor
with a regular VGA cable then you will be giving RGBHV to the monitor.
Be sure to not select sync-on-green or you will get a green cast to the
image.

Table 5-1 Standard Graphics Display Formats

Format Name
QXGA
WUXGA
UXGA
SXGA+
SXGA
QVGA
SVGA
Pixel
Resolution
2048 x 1536
1920 x 1200
1600 x 1200
1400 x 1050
1280 x 1024
1280 x 960
XGA 1024 x 768
800 x 600
VGA 640 x 480
Aspect Ratio
4:3
8:5 (HDTV)
4:3
4:3
5:4
4:3
4:3
4:3
4:3
