Table 1-1 Board Feature Summary

Silicon Motion SM731 2D/3D engine with 16MB SDRAM
1600x1200 single VGA
1024x768 dual VGA
1280x1024 single/1024x768 dual LVDS
1600x1200 single DVI
S-Video/NTSC/PAL/SECAM single output
Interlaced/non-interlaced, Sync-On-Green
STANAG 3350 A-C output option
DVI Input mode
RGBHV, RGB, and STANAG Input modes
S-Video/NTSC/PAL/SECAM Input modes
Dual front panel VGA connector option
Dual VGA via DVI b/o cable option
Dual VGA rear panel option
LVDS options – front/rear
MDR26 LVDS front panel connector option
Single DVI options – front/rear
Composite/S-Video output
MDSM-16 Video I/O connector
MDR20 Video I/O connector
2 Kb serial EEPROM and LM75 thermal sensor
3.3V & 5V PCI Bus Signaling
33/66 MHz PCI Bus Speed
CCPMC form factor compatible
Full CCPMC version with thermal layers
Local 3.3V regulator
Side 1 only component loading
Field reprogrammable VGA BIOS
SDL Graphics Subroutine Package
SDL-based WindML and BIT
Windows 2K/XP graphics drivers
Windows 2K/XP video input drivers
Xfree86 Version 4.3 for Linux and VxWorks
X video in extensions for Linux and VxWorks
RG-101 Rear I/O compatible version (PCB Rev 1)
Rastergraf
Stratus/ Tropos/
Topaz
Garnet Duros
yes yes
yes yes
yes yes
yes yes
yes yes option
yes yes Duros
yes yes Duros
yes
no Duros
yes yes
yes yes
yes yes
yes no
yes Stratus
yes yes
yes rear only rear only
yes n/a
yes yes
yes yes
no Stratus
yes no
yes yes
yes yes
yes yes
yes yes
no Garnet Duros
yes Stratus Tropos
yes yes
yes yes
yes yes
yes yes
yes yes
yes yes
yes yes
yes yes
yes no
