1.3 Video Capture and Playback

The Topaz, Stratus, and Garnet are ideal solutions for industrial graphics
applications. They combine a powerful hardware graphics engine with
support for multiple display devices including VGA, DVI, and LVDS
displays, and NTSC/PAL video monitors.
They also provide video capture support from NTSC/PAL rate and
RGBHV or DVI up to SXGA enabling real-time full-frame-rate display of
live video as well as "frame-grabber" functionality that can upload images
to the host.
Video input may be easily included in a wide variety of applications. The
use of video input can greatly benefit control and monitoring applications
as a fundamental component of the user interface.

Figure 1-8 Video Capture and Playback Support

Video Input Source
(camera)
Station 1
Display
PMC Host CPU
VMEbus or
CompactPCI
System
