3.5 MDR26 Connector

The TopazPMC/1L uses a 26-pin 3M #10226-1210VE female MDR26
connector to provide single high resolution (1600x1200) or dual medium
resolution (1024x768) LVDS output(s) on the PMC front panel. The
TopazPMC/2L and /2N can provide a single medium resolution
(1024x768) LVDS output plus a variety of NTSC/PAL, high-speed RGB,
or DVI input functions.

Table 3-7 Video I/O (VI/O) Front Panel Connector (Pinouts 26A-26C)

MDR26 Pin
Number
1, 14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13, 26
3.5.1 MDR26 Pinout 26A – Video In, Video Out, Ch 1 LVDS Out
The MDR26 Pinout 26A supports dual use pins. The NTSC/PAL and
high-speed RGB video input signals are connected together on the board.
They are shown in the table to illustrate the different capabilities of the
board.
NTSC/PAL Input
VIN0-VIN3 are composite NTSC/PAL Inputs and CIN is an input
dedicated to Chrominance. VIN 0 can be used with the CIN for S-Video
MDR26
Pinout 26A
Ground
YOUT
VOUT
YIN_VIN0/HS_RED
VIN1/HS_GREEN
Ground
Ground
COUT
CIN /HS_VSYNC
VIN2/HS_BLUE
VIN3/HS_HSYNC
Ground
F5V
FLVDSA_TX3P
FLVDSA_TX3N
FLVDSA_TXCP
FLVDSA_TXCN
FLVDSA_TX2P
FLVDSA_TX2N
FLVDSA_TX1P
FLVDSA_TX1N
FLVDSA_TX0P
FLVDSA_TX0N
Ground
MDR26
Pinout 26B
Ground
DVI_IN_ TXCLKN
DVI_IN_ TXCLKP
DVI_IN_ TX1P
DVI_IN_ TX1N
Ground
Ground
DVI_IN_TX2N
DVI_IN_TX2P
DVI_IN_ TX0P
DVI_IN_ TX0N
Ground
F5V
FLVDSA_TX3P
FLVDSA_TX3N
FLVDSA_TXCP
FLVDSA_TXCN
FLVDSA_TX2P
FLVDSA_TX2N
FLVDSA_TX1P
FLVDSA_TX1N
FLVDSA_TX0P
FLVDSA_TX0N
Ground
Connector Pinouts and Cable Information 3-11
Rastergraf
MDR26
Pinout 26C
Ground
FLVDSB_TX3P
FLVDSB_TX3N
FLVDSB_TXCP
FLVDSB_TXCN
FLVDSB_TX2P
FLVDSB_TX2N
FLVDSB_TX1P
FLVDSB_TX1N
FLVDSB_TX0P
FLVDSB_TX0N
Ground
F5V
FLVDSA_TX3P
FLVDSA_TX3N
FLVDSA_TXCP
FLVDSA_TXCN
FLVDSA_TX2P
FLVDSA_TX2N
FLVDSA_TX1P
FLVDSA_TX1N
FLVDSA_TX0P
FLVDSA_TX0N
Ground
