4.7 Finishing the Installation

4.7.1 Connecting to the Monitor

Be sure to snug the connector's thumbscrews down, as it may otherwise
work loose and cause unreliable operation.
Connecting to the Pn4
Note that because of the specialized nature of the work, Rastergraf does
not supply standard cables or any adapters for use with boards with Pn4
(rear panel) connections. You are on your own for cabling.
Connecting to the TopazPMC/1V or TroposPMC/1V
If you have a non-DVI capable TopazPMC/1V or TroposPMC/1V board,
you can plug VGA cable(s) directly into the VGA compatible front panel
connector(s).
Note
Because two VGA connectors are a tight fit on a PMC board, some VGA
cable connector moldings are too wide to allow two cables to be plugged
in simultaneously on the GeminiPMC/1. Rastergraf can supply cables that
are known to fit. Please see
Connecting to the TroposPMC/1V
If you have a TroposPMC/2 (with DVI), plug your DVI monitor cable into
the DVI-I connector on the front panel. If you wish to use VGA instead,
plug a DVI-VGA adapter into the Tropos DVI connector and connect the
other end to the VGA cable.
Connecting to the TopazPMC/1L
If you have a TopazPMC/1L (LVDS), you can plug a VGA monitor cable
into the VGA connector on the front panel. Alternatively, and more likely,
you can connect one or two LVDS panels to the MDR26 connector using
a custom or standard cable (see Chapter 3).
Section 3.8.
Installing Your Rastergraf Graphics Board 4-21
