Rastergraf Topaz User Manual page 115

Installation Procedure
Note:
Refer to
Section 4.3.3
1. Shut down the operating system and turn off the power.
Warning!
Never open the computer without turning off the power supply. Unless
internal AC wiring is exposed, leave the power cord plugged in, so as to
ground the computer chassis. You can easily get shocked, ruin computer
parts or both unless you turn off the power. Even with power switched off,
lethal voltages can exist in the equipment.
2. Open the computer and remove the CPU board onto which the
graphics PMC board is to be installed. Identify an empty PMC location
(generally there are one or two on a given CPU board). The graphics
PMC board is a Universal PMC/PCI device and can be plugged into a
PMC port which uses either 5V or 3.3V signaling.
THE CARRIER MUST SUPPLY BOTH 3.3V AND 5V unless the
graphics board has a local 3.3V regulator installed.
3. Take care to optimize airflow by blocking off unused slots in the card
cage, and arrange the boards to permit optimum airflow through them.
Caution
The static electricity that your body builds up normally can seriously
damage the components on the graphics board.
for the settings for JP1 – JP4.
Installing Your Rastergraf Graphics Board 4-11
