3.18 StratusPMC Video I/O Breakout Cable

The StratusPMC Video I/O Breakout Cable uses the MDSM15 connector
to bring in NTSC/PAL/S-Video and high speed RGBHV video inputs and
provide composite and S-Video out. It is used on the StratusPMC
versions which have the MDSM connector documented in
Section 3.9

Figure 3-10 MDSM to BNC Breakout Cable (A31-00735-0036)

Table 3-22 StratusPMC Video I/O Breakout Cable (A31-00735-0036)

MDSM Connector Connector
Pin Number
1 C1
9 C1
2 C2
9 C2
3 C3
10 C3
4 C4
11 C4
5 C5
12 C5
6 C6
13 C6
7 C7
14 C7
8 C8
15 C8
for the BNC to S-Video Adapter.
Connector
Pin Type
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
center male BNC
shell male BNC
Wire
Type Function
75 coax #BLK Video Out
75 coax # BLK Video Out
75 coax #BRN Video Out
75 coax # BRN Video Out
75 coax #RED Video Out
75 coax # RED Video Out
75 coax #ORG Video In
75 coax # ORG Video In
75 coax #YEL Video In
75 coax # YEL Video In
75 coax #GRN Video In
75 coax # GRN Video In
75 coax #BLU Video In
75 coax # BLU Video In
75 coax #VIO Video In
75 coax # VIO Video In
Connector Pinouts and Cable Information 3-31
Rastergraf
Section 3.6. See
C1
C2
C3
C4
C5
C6
C7
C8
Description
Name
YOUT
Ground
VOUT
Ground
COUT
Ground
CIN/HS_VSYNC
Ground
YIN_VIN0/HS_RED
Ground
VIN1/HS_GREEN
Ground
VIN2/HS_BLUE
Ground
VIN3HS_HSYNC
Ground
