3.9 S-Video Adapter Cables

The TopazPMC/2 VIO breakout cable has two S-Video connectors, one
for input and one for output (see
S-Video cable can be used as a standard composite input. The
A31-00709-1003 S-Video to BNC adapter cable is supplied for that
purpose.

Table 3-10 TopazPMC S-Video to BNC adapter cable (A31-00709-1003)

BNC
(P2)
Pin
2
1

Figure 3-3 S-Video to BNC Adapter (A31-00709-1003)

S-Video Wire
Pin Type
3 75 coax #BLK
1 75 coax # BLK
Section 3.8). One pin on the input
Description
Function Name
Video In Composite Video In
Video In Ground
Connector Pinouts and Cable Information 3-17
