Getting Help

This installation manual gives specific steps to take to install your
Rastergraf board. There are, however, variables specific to your computer
configuration and monitor that this manual cannot address. Normally, the
default values given in this manual will work. If you have trouble
installing or configuring your system, first read Chapter 6,
"Troubleshooting". If this information does not enable you to solve your
problems, do one of the following:
1) call Rastergraf technical support at: (541) 923-5530
2) send E-mail to:
If your problem is monitor related, Rastergraf technical support will need
detailed information about your monitor.

Board Revisions

This manual applies to the following board revision levels:
Tropos/Stratus Fab Rev 1
Duros/Garnet Fab Rev 1
Topaz Fab Rev 0, 1, 2
Manual Revisions
Revision 3.1
Revision 3.2
Revision 3.3
Revision 3.4
Revision 3.5
Revision 3.6
Revision 3.7
Introduction - 2
April 2007
September 2007
February 12, 2008
December 6, 2013
January 6, 2014
February 7, 2017
May 5, 2017
support@rastergraf.com
Rastergraf version
Update RIO info
Fix part numbers, add
LVDS info, change cable info.
Changes for Topaz Rev 1.
Remove fax, update address, add
RG-101 pinout
clean up some text in Ch. 3
clean up and correct tables in
Section 3.20.
Changes for Topaz Rev 2.
Moved jumpers, added option for
VGA Ch 2 on Ch 1 on DVI-I
.
