Table 2-4 SDL Platform Display Timing Specifications

Active Analog/
Display DVI
640 x 480 Both
800 x 600 Both
1024 x 768 Both
1152 x 900 Analog
1280 x 1024 Both
1600 x 1200 Analog
Bits per Vertical
Format
Pixel Refresh
VGA 8, 16, 32
SVGA 8, 16, 32
UVGA 8, 16, 32
Sun 8, 16, 32
SXGA 8, 16, 32
UXGA 8, 16, 24
Horizontal
Refresh
75 Hz 37.65 kHz
75 Hz 47.03 kHz
75 Hz 60.15 kHz
72 Hz 67.54 kHz
75 Hz 80.17 kHz
75 Hz 93.98 kHz
Specifications 2-11
Rastergraf
Pixel
Clock
30.72 MHz
48.90 MHz
81.80 MHz
103.74 MHz
138.54 MHz
204.49 MHz
