ANT-20SE
1.3.5

Error insertion (anomalies)

The following anomalies can be inserted in addition to those in the mainframe instrument:
Anomaly
B1 (STM-64/OC-192)
B2 (STM-64/OC-192)
MS-REI (STM-64)
REI-L (OC-192)
Table S-2
The insertion of errors (anomalies) or alarms (defects) are mutually exclusive. The action
selected first is active.
1.3.6

Alarm generator (defects)

The following defects can be generated in addition to those in the mainframe instrument:
.
Defect
-
LOS (optical)
LOF-9953
RS-TIM (STM-64)
TIM-L (OC-192)
MS-AIS (STM-64)
AIS-L (OC-192)
MS-RDI (STM-64)
RDI-L (OC-192)
Table S-3
The insertion of alarms (defects) or errors (anomalies) are mutually exclusive. The action
selected first is active.
Specifications STM-64/OC-192
Single
yes
yes
yes
Anomalies available in addition to the mainframe instrument
Test sensor Test sensor thresholds
function
On/Off M in N
yes M = 800 to 7200
N = 1600 to 8000
yes M = 1 to N - 1
N = 1 to 8000
yes -
yes M = 1 to N - 1
N = 1 to 8000
yes M = 1 to N - 1
N = 1 to 8000
Defects available in addition to the mainframe instrument
Optical Interfaces; STM-64/OC-192
Rate Burst m, n (frames)
1E-10 to 2E-5 m = 1 to 196000
1E-10 to 1E-3 m = 1 to 196000
1E-10 to 1E-3 m = 1 to 196000
|----t1----|
|-----t2-----|
t1 = 0.1 to 60.0 s
t2 = 0.2 to 600 s
t1 = 0.1 to 60.0 s
t2 = 0.2 to 600 s
-
t1 = 0.1 to 60.0 s
t2 = 0.2 to 600 s
t1 = 0.1 to 60.0 s
t2 = 0.2 to 600 s
S-57
