Wavetek ANT-20 Operating Manual page 43

Advanced network tester

Hide thumbs Also See for ANT-20:

Table of Contents

ANT-20SE

Interface

DS1

The bit rates depend on the mapping options fitted.

Table S-10

LOS (Loss of Signal) status display

LED lights up if the signal input is active but no signal is present.

The balanced input is used both as "LINE" and as "AUXILIARY" input.

Specifications STM-0/1/4/OC-1/3/12

Bit rate (Mbit/s)

2.048

1.544

Specifications of the LINE/AUXILIARY signal input [12], electrical

Optical Interfaces; STM-0/1/4/OC-1/3/12

Line code

HDB3

B8ZS

Input voltage

3.0 V ±10 %
