ANT-20SE
1.3

SDH and SONET TX signals

• Generates a STM-64 signal conforming to ITU-T recommendation G.707.
• Generates an OC-192 signal conforming to the Bellcore-GR-1377 standards.
1.3.1

STM-64 TX signal

STM-64 signal formation:
• one AUG1 signal (STM-1 level), generated internally x 64 (64 x AU-4 or 192 x AU-3)
• one AUG4 signal (STM-4c level)
• one AUG16 signal (STM-16c level)
• one AUG1 signal (STM-1 level), generated internally (AU-4 or AU-3), the other
63 AUG1 signals loaded with HP-UNEQ
• one AUG4 signal (STM-4c level)
with HP-UNEQ
• one AUG16 signal (STM-16c level)
with HP-UNEQ
1 Also see "Concatenated Mappings OC-12c/STM-4c OC-48c/STM-16c" operating manual
1.3.2

OC-192 TX signal

OC-192 signal formation:
• one STS-1 signal, generated internally x 192
• one STS-3c signal, generated internally x 64
• one STS-12c signal
• one STS-48c signal
• one STS-1 signal, generated internally, the other 191 STS-1 signals loaded with UNEQ
• one STS-3c signal, generated internally, the other 189 STS-1 signals loaded with UNEQ
• one STS-12c signal
• one STS-48c signal
1 See also Operating Manual "Concatenated Mappings OC-12c/STM-4c OC-48c/STM-16c"
1.3.3

Scrambling

Scrambling is as per ITU-T recommendation G.707, ANSI Standard T1.105 and
Bellcore GR-253.
The scrambler cannot be switched off.
Specifications STM-64/OC-192
1
, generated internally x 16 (16 x AU-4-4c)
1
, generated internally x 4 (4 x AU-4-16c)
1
, generated internally, the other 60 AUG1 signals loaded
1
, generated internally, the other 48 AUG1 signals loaded
1
, generated internally x 16
1
, generated internally x 4
1
, generated internally, the other 180 STS-1 signals loaded with UNEQ
1
, generated internally, the other 144 STS-1 signals loaded with UNEQ
Optical Interfaces; STM-64/OC-192
S-49
