ANT-20/ANT-20E
4.3

Error insertion (anomalies)

Trigger modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Single or Rate
Error type, anomaly
FAS
EM (BIP-8)
REI
Table S-3
4.4 Error measurement (anomalies)
The following anomalies can be evaluated and displayed in addition to those described in the
Mainframe "Specifications".
Anomaly
FAS
EM (BIP-8)
REI
Table S-4
4.5 Alarm detection (defects)
The following defects can be evaluated and displayed in addition to the alarm types described
in the Mainframe "Specifications".
Defect
AIS
LOF
RDI
UNEQ
PLM
TIM
Table S-5
Specifications
Available error types (anomalies) and trigger modes
LED
FAS
B1/B2
-
LED indication of possible anomalies
LED
AIS
LOF/OOF
RDI
HP-UNEQ
HP-PLM
-
LED indication of possible defects
Single
Yes
Yes
Yes
ATM Mappings
Rate
2E-3 to 1E-8
2E-3 to 1E-10
5E-5 to 1E-10
S-5
