ANT-20SE
2.3

Measurement modes

2.3.1

Alarm detection (defects)

The following alarms can be evaluated and displayed in addition to the alarm detection
functions given in the mainframe instrument:
Defect
LOS (optical)
LOF-2488
RS-TIM (STM-16)
TIM-L (OC-48)
MS-AIS (STM-16)
AIS-L (OC-48)
MS-RDI (STM-16)
RDI-L (OC-48)
Table S-4
2.3.2

Error measurements (anomalies)

The following anomalies can be evaluated and displayed in addition to the error measurements
given in the mainframe instrument:
Anomaly
OOF-2488
B1 (STM-16, OC-48)
B2 (STM-16, OC-48)
MS-REI (STM-16)
REI-L (OC-48)
Table S-5
Evaluation and display of B2 errors (STM-16, OC-48) refers to all test channels taken together.
Specifications STM-16, OC-48
LED
LOS
LOF/OOF
-
MS-AIS/AIS-L
MS-RDI/RDI-L
LED displays for additional defects
LED
LOF/OOF
B1/B2
B1/B2
-
LED displays for additional anomalies
Optical Interfaces; STM-16/OC-48
S-33
