Section overhead (SOH) #1 to #64,
Transport overhead (TOH) #1 to #192 evaluation
Display
• SOH #1, TOH #1
• Trace Identifier J0 (STM-64/OC-192)
Evaluation
Bit error measurement
• with PRBS11 pseudo-random sequence:
Output
The overhead channels are output
• in bytes via DCC/ECC interface, socket [21] (V.11):
• in byte groups via DCC/ECC interface, socket [21]
(V.11):
Specifications STM-64/OC-192
Optical Interfaces; STM-64/OC-192
hexadecimal
Except: B1, B2, H1 to H3
ASCII, plain text
E1, F1, E2 (single byte)
D1 to D3, D4 to D12 (byte group)
E1, F1, E2 (single byte)
D1 to D3, D4 to D12, K1 to K2
(byte group)
