Note for ANT-20SE users

The following hardware and software bundles have been formed for the ANT-20SE.
Assignments of modules and software ANT-20SE – ANT-20/ANT-20E:
Table O-6
Specifications STM-64/OC-192
Module / Software
Mainframe, SDH
Mainframe, SONET
Extended SDH Testing
Extended SONET Testing
Add SONET
(SONET expansion for SDH mainframe)
Add SDH
(SDH expansion for SONET mainframe)
Drop&Insert (Through mode, Block&Replace) 3060/90.10
PDH MUX/DEMUX (64/140)
M13 MUX/DEMUX
STM-1, OC-1/3 1310 nm
STM-1, OC-1/3 1310 nm & 1550 nm
STM-1/4, OC-1/3/12 1310 nm
STM-1/4, OC-1/3/12 1310 nm & 1550 nm
Optical power splitter
OC-12c BULK
OC-12c Virtual concatenation
Assignments of modules and software
Optical Interfaces; STM-64/OC-192
BN number Equivalent BN number
ANT-20SE
3060/01 3035/41 or 3035/21
+ 3035/92.15
+ 3035/93.11
+ 3035/90.01
3060/02 3035/42 or 3035/22
+ 3035/92.15
+ 3035/93.11
+ 3035/90.10
3060/90.01 3035/90.02, 3035/90.03,
3035/90.04, 3035/90.05,
3035/90.06, 3035/90.15
3060/90.02 3035/90.11, 3035/90.12,
3035/90.13, 3035/90.03,
3035/90.15
3060/90.03 3035/90.10, 3035/90.11,
3035/90.12, 3035/90.13,
3035/90.34
3060/90.04 3035/90.01, 3035/90.02,
3035/90.04, 3035/90.05,
3035/90.06, 3035/90.33
3035/90.20
3060/90.11 3035/90.30
3060/90.12 3035/90.32
3060/91.01 3035/90.43 + 2 Adapters
3060/91.02 3035/90.45 + 2 Adapters
3060/91.11 3035/90.46 + 2 Adapters
3060/91.12 3035/90.48 + 2 Adapters
3060/91.05 3035/90.49 + 3 Adapters
3060/90.90 3035/90.90
3060/90.92 3035/90.92
