ANT-20SE

Specifications STM-0/1/4/OC-1/3/12

The numbers in square brackets [...] correspond to the numbers printed on the instrument.
Calibrated specifications are indicated by ***.
1

Generator section

1.1

Digital signal output

1.1.1

Signal output [18], optical

Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5 mm (PC)
"Fiber-to-fiber" adapter for direct connection to various
2.5 mm connector types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see list of accessories
Output level *** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 dBm +2/-3 dBm
Reduction in output level for 2 wavelength version . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5 dBm
Output signal pulse shape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .to ITU-T G.957
Wavelength (switchable, depending on option) . . . . . . . . . . . . . . . .1310 nm (1280 to 1330 nm)
Laser class to EN 60825-1:1994 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
The generator fulfills the requirements of ITU-T G.957, classes L1.1, L1.2, L1.3, L4.1, L4.2 and
L4.3. The classes S1.1, S1.2 and S4.1 and S4.2 can be achieved by inserting an optical
attenuator or the optical power splitter BN 3035/90.49.
LASER ON status display
LED is on when the laser source is active.
Specifications STM-0/1/4/OC-1/3/12
Optical Interfaces; STM-0/1/4/OC-1/3/12
1550 nm (1480 to 1580 nm)
S-1
