SOH byte loading
• Static bytes:
• Overhead sequence m, n, p:
• Trace Identifier:
• Dynamic byte groups with pseudo random
bit sequence PRBS11:
• Dynamic byte groups with pseudo random
bit sequence PRBS11:
• Dynamic bytes via DCC/ECC interface,
Socket [21] (V.11):
• Dynamic byte groups via DCC/ECC
interface, Socket [21] (V.11):
STM-1, STM-0, OC-3, OC-1 standard overhead
See separate operating manual "STM-1 mappings/STS-1 mappings".
1.3.9

Error insertion (anomalies)

The following anomalies can be inserted in addition to those in the mainframe instrument:
Anomaly
B1 (STM-4, OC-12)
B2 (STM-4, OC-12)
MS-REI (STM-4)
REI-L (OC-12)
Table S-2
The insertion of errors (anomalies) or alarms (defects) are mutually exclusive. The action
selected first is active.
Specifications STM-0/1/4/OC-1/3/12
Single
yes
yes
yes
Available anomalies in addition to the mainframe instrument
Optical Interfaces; STM-0/1/4/OC-1/3/12
All except B1, B2, H1, H2, H3
All except B1, B2, H1, H2, H3
J0 (Length = 16 frames with CRC7 formation)
E1, F1, E2 (single byte)
D1 to D3, D4 to D12 (byte group)
E1, F1, E2 (single byte)
D1 to D3, D4 to D12, K1 to K2 (byte group)
Rate
2E-4 to 1E-10
2E-3 to 1E-10
2E-3 to 1E-10
Burst m, n (frames)
m = 1 to 196000
m = 1 to 196000
m = 1 to 196000
S-5
