11.3 IP configuration menu

This menu is used to configure the IP parameters of the SIGMA.
To enter the SIGMA IP configuration menu,
validate the option in the technician menu
with the key
The following screen is displayed :
If DHCP =YES, then it is the network's DHCP
2
server which gives the product its IP parameters.
If you wish to give the SIGMA a fixed address, validate this option (set to No)
with the key
The following screen is displayed:
Enter the IP address and then validate.
The following screen is displayed:
Enter the sub-network mask and then
validate.
The following screen is displayed:
Enter the address of the gateway and
validate the option in the technician menu
with the key
This data is neither saved nor present in the printing.
After validation, the master clock restarts automatically to take into account
the DHCP changes.
2 Dynamic Host Configuration Protocol (DHCP) is a term designating a network
protocol which carries out automatic configuration of the IP parameters of a station, notably by
automatically assigning it an IP address and a sub-network mask.
38
,
,
,
IP setting
Relay setting
DHCP : No
IP Address fixed ok
IP Address :
---.---.---.--- ok
Subnet Mask
---.---.---.--- ok
Gateway :
---.---.---.--- ok
ok
