Flashforge Creator Pro User Manual page 28

6.2.11 Print
FlashPrint - untitle.fpp
File E dit Print View T ools
View
Move
Rotate
Scale
Cut
Extruder
FlashForge Creator Pro
1. Preview: Choose to enter preview interface or not.
2. Machine Type:
3. Material Right/Left: Choose a type of material according to the type of model.
4. Supports: When print suspended structure models, support is necessary.
Click [Supports] to create support part for the printing.
5. Raft: This function will help the model to stick well on the platform.
6. Wall: During dual color printing, this function will help to clear the leaking filament of
another extruder.
7. Brim: Expand the outline of model's bottom layers to a brim which helps anchor the
edges of model to the plate to avoid warping.
8. Resolution: You have three resolution solution(with default setting)to choose from, high
resolution is corresponding with slow printing speed, opposite for the low
resolution. For PLA printing, an extra solution "Hyper" is available.
9. More options: Click [More options] to set for layer, shell, infill, speed and temperature.
Different resolution solution is corresponding to different defaults, click
[Restore Defaults] to back to default setting.
Layer Height
Help
Load
Print
I want to: Preview
FlashForge Creator Pro
Machine Type:
ABS
Material Right:
Material Left:
ABS
Supports: Automatch
Raft:
Right Extruder
Resolution: Low (Faster)
Standard
High (Slower)
More Options >>
Layer Height Shells Infill Speed Temperature Others
Layer Height:
0.18mm
First Layer Height: 0.27mm
OK Cancel
Layer Height: Layer thickness of the printing model. With a
small value, the surface of the model will be smoother.
First Layer Height: This is the first layer of the model, which
will affect the sticking performance between the model and
platform. Maximum is 0.4mm, and usually the default is OK.
27
Supports Print
Wall
Brim
Restore Defaults
Save Configuration
