Flashforge Creator Pro User Manual page 27

Supports Options
Supports Type:
45°
Overhang Thresh:
3 . 0mm
Post Diameter:
6 . 0mm
Base Diameter:
6 . 0mm
Base Height:
A
2. Auto Supports
Click the [Auto Supports] button, the software will judge the position where supports are
needed and generate corresponding treelike or linear supports. If it is a model with supports,
the existing supports will be deleted and new supports will be generated.
3. Add Supports
Supports will be added once clicking the [Add] button. Move the cursor to the position where
supports needed, left-click to choose the starting point of supports, hold down the left mouse
button and drag the mouse the supports preview will show up(if support surface doesn't need
support or the support column angle is too large, the support review will be highlighted ).
Loosen the left mouse button, if support column doesn't meet with model, then support will be
generated on origin and terminal point(the highlighted preview support won't generate support
structure )
3. Clear Supports
Click [Clear Supports], all supports will be deleted. The operation can be repealed via clicking
[Undo] or pressing the shortcut key Ctrl+Z.
4. Delete Supports
Supports will be deleted once clicking the [Delete] button. Move the cursor to the supports
needed deleting, current supports and its subnode support will be highlighted, click the left
mouse button to delete these highlighted support.
Treelike
OK Cancel
26
Linear
Restore Defaults
Treelike
