6.2.3 Loading
You can load a model file or Gcode file into your FlashPrint by the following six methods:
Method 1: Click the Load icon on the main interface. Then select the object file.
Method 2: Select the file for loading and drag the file to the main interface of the software.
Method 3: Click [File] - [Load File]. Then select the object file for loading.
Method 4: Click [File] - [Examples] to load the example files.
Method 5: Click [File] - [Recent Files] to load the files opened recently.
Method 6: Select and click-drag the target file to the icon of FlashPrint.
Note: .STL, .OBJ, and .FPP, ways to store 3D models, are supported by FlashPrint for editing.
Generating Rilievo
Load a png, jpg, jpeg, bmp picture file into the FlashPrint. And the following dialogue box will pop up.
The setting box includes settings for shape, mode, maximum thickness, base thickness, bottom
thickness, width, height, top diameter and bottom diameter.
Shape: including plane, tube, canister and lamp.
Mode: including "darker is higher" and "lighter is higher".
Maximum thickness: Z value of the model.
Base thickness: The minimum raft thickness and the
default value is 0.5mm.
Width: X value of the model.
Depth: Y value of the model.
Bottom thickness: For tube, canister and lamp to set
up bottom thickness.
Top diameter: For tube, canister and lamp to set up the
top diameter.
Bottom diameter: For tube, canister and lamp to set
up the bottom diameter.
Plane
Convert image to stl
Shape：
Mode：
Base Thickness：
Miximum Thickness：
Width(X)：
Depth(Y)：
Tube / Canister
21
P l a n e
P l a n e
Tu b e
C a n i s t e r
L a m p
S e a l
2 2 4 . 0 0 m m
1 0 0 m m
1 0 0 m m
O K C a n c e l
