Ip Camera Viewer; Poe Power / 12Vdc 2A And 5Vdc 2A Usb Power Output - Security Tronix IP BUDDY+ User Manual

The IP camera and IP BUDDY+ ALL IN 1 must be on the same network segment for the browser to interface with the camera. If they are not in
button or press "RETRUN" to exit. Open the "Settings" app from the main menu to change the IP Buddy+'s
the same segment, click the
network settings to match those of the IP camera.
3.3.20 IPC viewer
In addition to the ONVIF app or the IPC Test app, you can use one of the mobile apps in the IPC Viewer folder. Click the "IPC Viewer" icon to
open the mobile apps folder. Select your IP camera's corresponding mobile app to connect to it.
Note：The Video Management apps are third party applications. SecurityTronix does not support these apps nor make any usage claims. We do
not assume any legal liability.
Click on the "update" icon at the top of the IPC Viewer screen to check for mobile app updates.

3.3.21 PoE power / 12VDC 2A and 5VDC 2A USB power output

When the tester is turned on, the 12VDC and 5VDC power output functions are automatically turned on. If the IP BUDDY+ ALL IN 1 is turned
off, the 5VDC USB can still be used to power an external USB device.
To use the PoE Power Output function, click on the icon and change the switch "ON" or "OFF".
The IP camera needs to be connected to the LAN port before you turn PoE Power on. If the IP camera supports PoE, the PoE power is delivered
via pins 1, 2, 3, and 6 on the LAN port. The IP BUDDY+ ALL IN 1 will display "48V ON" at the top of the screen when the POE power is still
on.
28
