While in the flashlight app, click the red button to turn on the LED lamp. Press it again to turn it off. If you don't press the red button to shut off
the lamp and press the
button to exit the app, the lamp will stay on. Click the Time Setting button to set a timer that will shut off the lamp.
3.3.17 PoE in line Voltage test
Click the
icon to enter the PoE voltage in line measurement app.
Connect a network cable from a PoE switch to the IP BUDDY+'s PSE IN port. Connect an IP camera or other PoE using node to IP BUDDY+'s
LAN port, the PoE voltage and the cable's pin connection status show on the screen.
Note：This test if for measuring the voltage being drawn by the PoE node and the IP BUDDY+ ALL IN 1 must be between the
PoE switch and the PoE node for this test to work.
Note: The PoE switch must be connected to the PSE IN port. The powered device such as IP camera or other PoE node must be
connected to the LAN port.
Note: Do not connect PoE power supply equipment (such as a PoE switch) to the tester's UTP/SCAN port; otherwise it will damage
the tester.
3.3.18 Calculator
Click the
icon to open the Calculator app.
3.3.19 Browser
Click the
icon to open the Browser app.
Type in the camera's IP address and press "Go" to access the IP camera's interface.
NOTE: You will not be able to view live video in the web browser. For viewing video, use the IP BUDDY+ ALL IN 1 live camera view apps.
27
