ContaminationSensor CS1000
CS1000 hydraulic installation
The direction of flow through the CS has to be from bottom to top. Use one
connection port as the INLET and the other as the OUTLET.
Depending on your order, the CS features the following hydraulic connection types:
(also see Chapter "Hydraulic connection types"):
Flange connection - The CS is screwed to a flange, connecting plate, manifold
•
mount or control block, with flow through the unit via ports C and D on the
bottom.
Ports A and B exist but are sealed with a screw plug.
Specify the operating pressure of the hydraulic system so the permissible flow for
the CS inlet is achieved.
Working overpressure
The CS will be destroyed.
► Observe the maximum operating pressure on the CS 1000 type label.
