ContaminationSensor CS1000
Status Signal (PIN 8)
The voltage of the status output signal is dependent on the status of the CS1000 as
shown in the table below:
HYDAC Filter Systems GmbH
CS1000 CAT-VIMS3478916 en 2009-04-15.doc
Status
CS is functioning correctly
Device error / CS not ready
Flow insufficient (Flow 2 low)
ISO <9.<8.<7
No measured value
(flow not defined)
en
Analog Output
Voltage U
U = 1.25 V
U = 1.50 V
U = 1.75 V
U = 2.00 V
U = 2.25 V
