Moving Objects; Grouping And Ungrouping Objects - Smart Technologies smart board User Manual

2. Move the cursor to the next object you want selected until the
cursor becomes a multi-directional, four-headed arrow. Then
press the Shift key and click once.
Both the first and subsequently selected object will appear
enclosed by individual selection rectangles.
To select all objects on the current page:
Choose Select All from the Edit menu.
All objects on the page will appear enclosed in individual selection
rectangles.

Moving Objects

You may need to occasionally rearrange objects on a page to suit a
developing or altered train of thought. Also, if the sheer number of
objects on the Board or current page becomes distracting, you can stack
them by moving them on top of one another.
NOTE: If you want to move an object to another Notebook page, use the
cut and paste operation described on page 34.
To move a single object or several objects:
1. Select the object(s) to be moved as described above.
2. Press, hold and drag to any other position on the page.
If you select several objects, moving any one of them will cause
the entire group to move as a single unit.

Grouping and Ungrouping Objects

You may want to group several Notebook objects into a single graphical
object, so that when you select one object in the group, the entire group
is automatically selected. The object group can then be moved, edited
and sized as a single object.
When selected, the original multiple selection boxes within the group will
be replaced by a single selection box. When you cut or copy a single
grouped selection, the grouping is retained in the pasted result. In
addition, the grouping is preserved across any number of file saves.
SMART Board User's Guide 31
