Your First Contact - Icom ID-880H Instruction Manual

Your first contact
Now that you have your ID-880H installed in your car or
shack, you are probably anxious to get on the air. We would
like to take you through a few basic operation steps to make
your first time "On The Air" an enjoyable experience.
1. Turning ON the transceiver
Before powering up your ID-880H, you may want to make
sure the audio volume and squelch level controls are set in
9–10 o'clock positions.
Although you have purchased a brand new transceiver, some
settings may be changed from the factory defaults because
of the Quality Control (QC) process. Resetting the CPU is
necessary to start from factory default.
[S.MW] [VFO/MHz]
While pushing and holding [S.MW] and [VFO/MHz] keys,
push and hold [ ] for 1 sec. to reset the CPU.
[SQL]
Partial reset
QUICK REFERENCE GUIDE
2. Selecting the operating frequency band
The ID-880H can use 2 m or 70 cm transmittable bands.
[BAND] [DIAL]
Push [BAND] then rotate [DIAL] to select the desired fre-
quency band.
• Push [BAND] again to return to frequency indication.
Using the HM-133
You can select the desired frequency band from the HM-133.
• 144 MHz band
Push
• 400 MHz band
Push
Frequency band initial is displayed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
VIII
