Technical specifications
7.4 Technical data
Main circuit board
Processor
RAM
Buffer memory
Expansion slots
Drive, memory medium
Hard disk drive, optional
Solid-state drive, optional
CFast memory card, optional
Floppy and CD-ROM drive
USB stick
Only to device USB port, not via USB hub
1
Graphics
Graphics controller
Graphics memory
Resolution, graphics memory
100
Intel Celeron N2807: Dual Core, 1.58 GHz, burst frequency
2.16 GHz, 1 MB 2nd level cache, 4.3W TDP
Intel Celeron N2930: Quad Core, 1.83 GHz, burst frequen-
cy 2.16 GHz, 2 MB 2nd level cache, 7.5W TDP
DDR3L memory up to 8 GB, 1× SODIMM modules / non-ECC
512 KB NVRAM
128 KB of this can be backed up at full load in the buffer time
of the power supply.
1 x PCIe x1 for PCIe x1 cards up to a length of 175 mm
The PCIe slot supports the "PCI Express 2.0" specification.
You can find additional information in the section "Power re-
quirements of the components".
≥ 320 GB, 2.5" HDD
≥ 80 GB, 2.5" SATA SSD
≥ 160 GB, 2.5" SATA SSD
4 GB or
8 GB or
16 GB
External, can be connected via USB port
External, can be connected via USB port
Integrated Graphic Controller
Up to 512 MB, shared memory
DisplayPort resolution:
640 × 480 pixels to 2560 × 1600 pixels
up to 512 MB, graphics memory is taken from the main
memory, dynamic UMA
Operating Instructions, 11/2016, A5E35782395-AB
1
SIMATIC IPC227E
